Highly Integrated ICs Readily Enabled by Design-in Support Software to Speed System Development and Enhance System Performance
DENVER – INTERNATIONAL MICROWAVE SYMPOSIUM (IMS) – June 21, 2022 – In IMS Booth #7078, pSemi® Corporation, a Murata company focused on semiconductor integration, announces the production readiness of two new mmWave ICs targeted for active antenna systems in 5G base stations, 5G customer premises equipment and point-to-point radio communication applications. In addition to the 8-channel beamforming front end and dual-channel up-down converter ICs, pSemi offers a complete support package of tools and technical expertise to simplify mmWave design and development. The new RF SOI ICs are the latest in our mmWave portfolio that offers full IF-to-RF coverage across the n257, n258, and n260 bands in the industry’s smallest form factors.
Read more for the highlights or click to access the beamformer and up-down converter product briefs.
“As the n257 band reaches global mainstream use, pSemi is pleased to introduce a suite of mmWave products and tools to support this growing demand. With an established history in high-frequency semiconductor innovation and manufacturing, pSemi has the expertise and infrastructure required to deliver mmWave solutions with the performance and quality our customers and partners can trust.”
Vikas Choudhary
VP of sales and marketing
[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][tm-portfoliobox h2=”Beamformer & Up-down Converter IC” h4=”Features & Benefits” txt_align=”left” reverse_heading=”true”][/tm-portfoliobox][vc_column_text]The PE188200 beamformer IC (n257 band) and PE128300 up-down converter IC (n257, n258 band) offer a wide range of features and benefits to 5G FR2 system designers, including:
- Smallest footprint per channel – Monolithically integrated RF SOI ICs with the industry’s smallest form factors make it easy to build large arrays without the need for extra routing.
- Full IF-to-RF coverage – Up-down converters can be paired with up to four pSemi beamformers to support massive-MIMO, hybrid-beamforming and other active antenna configurations.
Additionally, the PE188200 8-channel beamformer IC offers:
- Flexible antenna design – The 8-channel beamformer IC supports four dual-polarized or eight single-polarity antenna elements, and scaled configurations for optimum array gain, EIRP, and antenna directivity.
- Beamforming accuracy – Linear POUT at the desired EVM with low RMS phase and amplitude error for increased array gain and antenna directivity ensures accurate beamforming.
Additionally, the PE128300 dual-channel up-down converter IC offers:
- Highly integrated solution – Industry’s first dual-channel up-down converter saves expensive real estate with the smallest footprint.
- Low power consumption – Best-in-class up-down converter IC performance enables more efficient system thermal management.
- Minimize system impairments – Optimal I/Q balance adjustment and minimal LO leakage results in improved EVM performance.
[/vc_column_text][tm-portfoliobox h2=”mmWave Control Software” txt_align=”left” reverse_heading=””][/tm-portfoliobox][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]In addition to samples and evaluation kits (EVK) pSemi offers a complete support package of software tools and technical expertise to help customers get up to speed working with our beamformer ICs, up-down converter ICs, or arrayed combinations of both.
- Graphical User Interface (GUI)– The software GUI assures proper operation of register programming for effective, efficient code implementation.
- API Integration – Optimize your performance across channels with our GUI and API integration. Speed up software development and demonstration by embedding pSemi software within customer-specific code.
- Comprehensive User’s Manual – Thorough user’s manual for each product contains register programming requirements and operational details.
[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][tm-portfoliobox h2=”Technology & Quality Advantage” txt_align=”left” reverse_heading=””][/tm-portfoliobox][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]From prototypes to volume shipments, pSemi delivers performance, integration and reliability bundled in a mmWave support package built on 30+ years of high-frequency semiconductor expertise.
- RF SOI Innovation – 30+ years of RFIC design innovation, with technical experts seasoned in delivering the highest levels of integration in the industry’s smallest form factors.
- Patents & IP – Inventor of RF SOI technology with 1000+ patents that continue to push the boundaries of high-frequency semiconductor performance.
- Quality & Manufacturability – Backed by Murata, a trusted supplier with proven experience in high-volume manufacturing that meets the highest reliability and quality standards.
More Information
These discrete RFICs will be featured and demonstrated as a part of the Murata antenna-integrated module in the pSemi IMS Booth #7078 from June 21 to June 23, 2022.
For more information on the beamformer and up-down converter RFICs, contact the pSemi team.[/vc_column_text][vc_separator][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]
