| Product | Store | Datasheet | Description | Min Freq. | Max Freq. | Peak RF Voltage (Vpk) | Min Typ. Shunt Capacitance (pF) | Max Typ. Shunt Capacitance (pF) | Tuning Ratio | Min Typ. Quality Factor @ Cmin | Max Typ. Quality Factor @ Cmin | Interface | Package | Package (mm) | VDD Range (V) | ESD HBM (V) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PE64102 |  |  | 5-bit; 32 states | 100 MHz | 3000 MHz | 6 | 1.88 | 14 | 7.4:1 | 28 | 50 | SPI | 12L QFN | 2x2 | 2.3–3.6 | 2000 |
| PE64904 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 1.1 | 5.1 | 4.6:1 | 10 | 35 | SPI | 10L QFN | 2x2 | 2.3–3.6 | 1500 |
| PE64906 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 0.9 | 4.6 | 5.1:1 | 40 | 40 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
| PE64907 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 0.85 | 2.4 | 2.82:1 | 37 | 41 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
| PE64909 | | | 4-bit; 16 states | 100 MHz | 3000 MHz | 30 | 0.6 | 2.35 | 3.9:1 | 40 | 40 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
