RF Attenuators

RF Attenuators

Key Features

  • High linearity, fast switching time with wide bandwidth
  • Best-in-class attenuation error with fine attenuation steps
  • Monolithic CMOS solution that integrates RF, analog and digital
  • Excellent ESD protection and reliability

RF Product Catalog

View the pSemi 2025–2026 Product Catalog to see our complete RF product portfolio.

Download Here »

Glitchless RF Digital Step Attenuators

ProductStoreDatasheetDescriptionMin Freq.Max Freq.Min Typ. IL (dB)Max Typ. IL (dB)IIP3 (dBm)Attn Range (dB)Attn Step (dB)InterfaceBitsPackagePackage (mm)Attenuation Accuracy (dB @ 1 GHz)Switching TimeESD HBM (V)
PE43711
7-bit; 128 states9 kHz6 GHz1.32.4570.00–31.750.25/0.5/1.0Parallel (Latched, Direct), Serial724L QFN4x4±(0.15 + 1.5% of setting)275 ns3000
PE43712
7-bit; 128 states9 kHz6 GHz1.32.45570.00–31.750.25/0.5/1.0Parallel (latched, direct); Serial-addressable732L QFN5x5±(0.20 + 1.5% of setting)275 ns3000
PE43713
7-bit; 128 states9 kHz6 GHz1.32.45570.00–31.750.25/0.5/1.0Parallel (latched, direct); Serial-addressable732L QFN5x5±(0.20 + 1.5% of setting)275 ns3000

75Ω Wired Broadband RF Digital Step Attenuators

ProductStoreDatasheetDescriptionMin Freq.Max Freq.Min Typ. IL (dB)Max Typ. IL (dB)IIP3 (dBm)Attn Range (dB)Attn Step (dB)InterfaceBitsPackagePackage (mm)Attenuation Accuracy (dB @ 1 GHz)Switching TimeESD HBM (V)
PE4314
6-bit; 64 states1 MHz2500 MHz11.5580.00–31.500.5Parallel (latched; direct); Serial620L QFN4x4±(0.15 + 3% of setting)370 ns1500
PE43665
6-bit; 64 states1 MHz2000 MHz1.41.8520.00–31.500.5Parallel (latched; direct); Serial620L QFN4x4±(0.15 + 4% of setting)1 ns500

General-purpose RF Digital Step Attenuators

ProductStoreDatasheetDescriptionMin Freq.Max Freq.Min Typ. IL (dB)Max Typ. IL (dB)IIP3 (dBm)Attn Range (dB)Attn Step (dB)InterfaceBitsPackagePackage (mm)Attenuation Accuracy (dB @ 1 GHz)Switching TimeESD HBM (V)
PE4312
6-bit; 64 states1 MHz4000 MHz1.32.1590–31.500.5Parallel (Latched, Direct), Serial620L QFN4x4±(0.15 + 2% of setting)500 ns1500
PE43205
2-bit; 4 states35 MHz6 GHz0.51.05610.00–18.006Parallel212L QFN3x30.129 ns2000
PE43508
6-bit; 64 states9 kHz55 GHz2.25.9500.00–31.500.5/1.0Parallel (Latched, Direct), Serial, Serial Addressable6Flip Chip₋'+(1.00+4.5% of setting) / -1330 ns1000
PE43610
6-bit; 64 states9 kHz13 GHz1.63500.00–31.500.5/1.0Parallel (Latched, Direct), Serial, Serial Addressable624L LGA4x4'+(1.00+4.5% of setting) / -1330 ns1000
PE43614
6-bit; 64 states9 kHz45 GHz35.8500.00–31.500.5/1.0Parallel (Latched, Direct), Serial, Serial Addressable624L LGA4x4'+(1.00+4.5% of setting) / -1330 ns1000
PE43620
2-bit; 4 states50 MHz3000 MHz0.60.7610–18.06/12/2018Parallel212L QFN3x3±(–0.25/+0.40 of setting)30 ns2000
PE43650
5-bit; 32 states9 kHz6 GHz2.429580.00–15.500.5Parallel (Latched, Direct), Serial524L QFN4x4±(0.3/+0.30 of setting)4000 ns500
PE43670
7-bit; 128 states9 kHz4000 MHz1.92.4590–31.750.25Parallel (Latched, Direct), Serial Addressable732L QFN5x5±(0.2/+0.15 of setting)4000 ns500
PE43704
7-bit; 128 states9 kHz8 GHz1.32.9610.00–31.750.25/0.5/1.0Parallel (Latched, Direct), Serial, Serial Addressable732L QFN5x5'+(0.15 + 4.5% of setting), –(0.1 + 2% of setting)1100 ns1500
PE43705
7-bit; 128 states50 MHz8 GHz1.32.4580.00–31.750.25/0.5/1.0Parallel (Latched, Direct), Serial, Serial Addressable732L QFN5x5'+(0.15 + 1.5% of setting), –(0.1 + 1% of setting)1000 ns1500
