PE42429

UltraCMOS+™ SPDT RF Switch

      Operating frequency: 9 kHz to 8.5 GHz
      High isolation: 46 dB @ 6 GHz
      Low insertion loss: 0.8 dB @ 6 GHz
      High linearity: 65 dBm IIP3
      Fast switching time: 490 ns
      Operating temperature range: -40 to +105 °C
      Packaging: 12-lead 2.0 × 2.0 mm QFN
View Product Details

PE42448

UltraCMOS+™ SP4T RF Switch – PE42448

      Low insertion loss:
      ▪ 0.42 dB at 2.6 GHz typical
      ▪ 0.6 dB at 3.8 GHz typical
      High linearity IIP3: 88.5 dBm
      High power handling: 39.5 dBm RMS, 11 dB PAR
      +115 °C operating temperature
      Packaging: 20-lead 4 x 4 mm LGA
View Product Details

PE42544

UltraCMOS+™ SP4T RF Switch

      Operating frequency: 9 kHz to 8.5 GHz
      High isolation: 40 dB @ 6 GHz
      Low insertion loss: 1.4 dB @ 8.5 GHz
      High linearity: 61 dBm IIP3
      Fast switching time: 300 ns
      Operating temperature range: -40 to +105 °C
      Packaging: 20-lead 3.0 × 3.0 mm QFN
View Product Details

PE42020

UltraCMOS® True DC RF Switch

      High power handling
      Maximum voltage (DC or AC peak): ±10V on the RF ports
      Total harmonic distortion (THD): –84 dBc
      Configurable 50Ω absorptive or open reflective switch via a single pin (LZ)
      Packaging: 20-lead 4 × 4 mm QFN
View Product Details

PE42420

UltraCMOS® SPDT RF Switch

PCN – February 18, 2022: Product Specification

PCN – May 18, 2020: Manufacturing Site, Product Specification, Ordering codes change

PCN – July 6, 2018: Assembly Site, Manufacturing Site, Ordering Code

PCN – July 15, 2016: Wafer Fabrication Process – Dual Source, Ordering Code

PCN – October 15, 2015: Assembly Process – New package laminate, Ordering Code

      HaRP™ technology-enhanced
      High linearity
      High isolation
      Supports +1.8V control logic
      +105 °C operating temperature
      High ESD tolerance
View Product Details

PE42423

UltraCMOS® SPDT RF Switch

PCN – June 21, 2019: Wafer Fabrication Process, Ordering Code

PCN – September 2, 2016: Wafer Fabrication Process – Dual Source, Ordering Code

      802.11 a/b/g/n/ac support
      Wide supply range of 2.3V to 5.5V
      +1.8V control logic compatible
      Exceptional isolation
      High linearity across supply range
      High power handling
      Fast switching time of 500 ns
      High ESD tolerance
      Packaging: 16-lead 3 × 3 mm QFN
View Product Details

PE42424

UltraCMOS® SPDT RF Switch

PCN – October 20, 2020: Product Specification

      802.11 a/b/g/n/ac/ax, Wi-Fi 6E and ultra-wideband
      (UWB) support
      Exceptional isolation
      Fast switching
      High power handling
      High linearity across supply range
      1.8V control logic compatible
      105°C operating temperature
      High ESD tolerance
      Packaging: 6-lead 1.5 × 1.5 mm DFN
View Product Details

PE4257

UltraCMOS® SPDT RF Switch

      50Ω characteristic impedance
      Integrated 50Ω 0.25 W terminations
      High input IP3 > +55 dBm
      High isolation 64 dB at 1000 MHz
      Low insertion loss: typically 0.75 dB at 1000 MHz and 0.95 dB at 2000 MHz
      LV CMOS two-pin control
      Single +3 V supply operation
      Low current consumption: 8 µA
View Product Details

PE42422

UltraCMOS® SPDT RF Switch

      Symmetric SPDT reflective switch
      Low insertion loss
      Wide supply range of 2.3–5.5 V
      Excellent linearity
      High ESD tolerance
      Logic Select (LS) pin provides maximum flexibility of control logic
      Packaging: 12-lead 2 × 2 mm QFN
View Product Details

PE42426

UltraCMOS® SPDT RF Switch

      Best-in-class linearity across frequency band
      Exceptional harmonics
      Low insertion loss and high isolation performance
      High ESD performance of 3 kV HBM
      Packaging: 12-lead 3 × 3 × 0.75 mm QFN
View Product Details

PE42427

UltraCMOS® SPDT RF Switch

PCN – January 30, 2019: Product Specification

      Symmetric SPDT reflective switch
      Low insertion loss
      Low spurious performance of -163 dBm/Hz
      Wide supply range of 2.3-5.5V
      Excellent linearity
      High ESD tolerance
      Logic Select (LS) pin provides maximum flexibility of control logic
      Packaging: 12-lead 2 × 2 mm QFN
View Product Details

PE42722

UltraCMOS® SPDT RF Switch

PCN – August 16, 2019: Wafer Fabrication Process, Ordering codes change

      Supports DOCSIS 3.0/1 requirements
      Exceptional harmonics performance
      Best in class linearity across frequency band
      Low insertion loss and high isolation performance
      High ESD performance of 1.5 kV HBM
      Packaging – 32-lead 5 × 5 mm QFN
